Description

SIZE
Form factor ATX, µATX
Dimensions (h/w/d) 490 x 210 x 465mm
INSTALLATION DIMENSIONS
Height CPU cooler (max.) 150mm
Length graphics card (max.) 380mm
DRIVE BAYS
5.25″ external 1x
3.5″ external
3.5″ internal 4x
2.5″ internal 2x
FRONT CONNECTORS
USB 3.0 2x
USB 2.0 1x
Card Reader
Microphone 1x
Headphones 1x
POWER SUPPLY
ATX-PSU
FAN MOUNTING OPTION
Front 2x 120mm (1x serial, red LEDs, 3pin-connector)
Rear 1x 120mm (red LEDs, 3pin-connector, serial)
Side panel 1x 120mm (optional)
Top 2x 120mm (red LEDs, 3pin-connector, serial)
GUARANTEE / WARRANTY
Warranty 24 months
SCOPE OF DELIVERY & FEATURES
Scope of delivery
Case
Retail packaging
Screw set
Adapter 4x 3pin to 1x Molex
Features
Side panel with window
Removable dust filters at the bottom
Guide srews for internal mounting of 3.5″ HDDs
Serial SD- and Micro-SD – Card Reader
3x 120mm fans with red LEDs serial in the front, cap and rear
Translucent front panel and top
Separated SSD mounting option at the bottom
PSU mounting at the bottom
Intelligent cable management
Space for cards with a length of up to 37cm
Side panels with thumbscrews
USB 3.0, USB 2.0, card reader and Audio plug internal as block connectors
Stands
HD-Audio
